DC Dual Battery Charger
Dual battery charger, also known as "driving charger", is generally installed between the starting battery and the living battery. When the RV is driving, the engine is in operation, and the starting battery charges the living battery through it. When the car stops driving, it can also use solar panels to charge our living battery
Product size: 404x361x150mm (LxwxH)
DC charger input voltage: 11V-24VDC maximum output power: 385W
Battery input voltage: 12V
Solar input voltage range: 12-26V
Fuse output: 10AX6 40AX1
Applicable battery types: lead-acid AGM、 Calcium battery, lithium iron phosphate
LVD battery low voltage protection
Disconnecting voltage: 10.5V
Delay closure time: 60 seconds
LVD reconnection: 13V
